FieldpieceSDMN5: Dual Port Manometer for Static Air & LPG Pressure

SDMN5 Dual-Port Manometer
Use for - Static Pressure, Differential Pressure, LPG & Natural Gas Pressure
Measures duct pressures to balance air flow
Suitable for Static Air Pressure, LPG & CNG - Natural Gas Measurements
Resolution down to 0.01" WC for static pressure measurement
-60.0"WC to 60.0"WC  & -150.0 to 150.0 mBar, mmWC or PSI selectable ranges
The SDMN5 is a portable dual port manometer for use with measuring gas pressure, static pressure and pressure differential across Evaporator Coils, Condenser Coils or Filter Banks.
The SDMN5 includes a zero adjust and the Auto Power-Off (APO) function to conserve battery life. It also measures P1 or P2 pressure readings and calculates the difference between P1 and P2. Take static pressure measurements using the resolution mode of 0.01inWC or 0.01mBar.

1 - Year from Date of Purchase
​Excludes Consumables such as Filters, Gaskets, Leads, Batteries, Fuses, Sensors, Case etc

WHAT'S INCLUDED
Dual-Port Manometer SDMN5
2 – 3/16” Tubes with Brass Fittings
2 – 3/16” to 5/16” Tube Adapters - RMA316
9V Battery (installed)
Operator’s Manual

SKU
SDMN5
Brand
Fieldpiece
Shipping Weight
1.5000kg
Shipping Width
0.250m
Shipping Height
0.120m
Shipping Length
0.350m
Shipping Cubic
0.010500000m3
Unit Of Measure
ea
Assembled Length
0.350m
Assembled Height
0.120m
Assembled Width
0.250m
