Brand: SHANGFANG
Model: sf-134


Specifications
1. Termostat control
2. Double sensors
3. For fan cooling&low temperature control
4. Range: -45 to 45 oC
   Digital Termostat  SF-105
 Features
1 For air cooling of low temperature
2 Double sensors
3 Temperature control
4 Evap.Fan control
5 Automatic/Manual defrost by electric heater/hot gas
6 High/Low temperature alarm
7 Time/Temp.setting to end defrost
8 Re-start delay
9 Celsius/Fahrenheit degrees
10 Mini-sized and integrated intelligent controller
11 Applicable to the compressor of 1HP

Technical Data
1 Range of temperature displalyed:-45°C~45°C(-40°F~120°F)
2 Range of set temperature:-45°C~45°C(-40°F~120°F)
3 Accuracy:±1°C(± 2°F)
4 Compressor:NO.20A/250VAC
5 Defrost:NO.10A/250VAC
6 Evap.Fan:NO.5A/250VAC
7 Output of the outside sealed transformer:12VAC
8 Temperature sensor:NTC,2pcs(for cold room temp.&defrost control),2m(L)
9 Temperature of the operating environment:-10°C~60°C
    Relative humidity:20%~90%(Non-condensing)
10 Dimension:77(L)x35(W)x60(D)mm
11 Mounting hole dimension:71(L)x29(W)mm

 Circuit diagram
