FieldpieceSMG5: Megohm Meter with Leads, Clips & Case
SMG5 - Fieldpiece Digital Megohm Meter.
The SMG5 is a compact standalone meter designed for checking HVAC-R compressor motor insulation.
The SMG5 provides a 1000V voltage source, monitors current, and displays the resistance between the test points.
Maximum current output is <1mA. It can be used to determine the condition of insulation from winding to ground in a motor, compressor, or transformer.
To test resistance, a DMM supplies low voltage (<1V) to the test points and is capable of delivering only a few milliamps. It's not a high enough voltage to detect high resistance problems that might indicate moisture and other contaminants and it's not enough current to measure lower values of resistance.
- Predict compressor failure
- 1000VDC stresses insulation to measure up to 2000Mohms
- Backlit LCD display
- Auto-off to extend battery life
- Case, alligator clip, leads with removable tips
(SMG5)
1 - Year from Date of Purchase
Excludes Consumables such as Filters, Gaskets, Leads, Batteries, Fuses, Sensors, Case etc
Whats Included
- Megohm Meter – SMG5
- (2) Probe Tips
- (1) Ground Lead with Detachable Tip
- (1) Alligator Probe Tip
- Carrying Case
- (4) AAA Batteries (installed)
- Operator’s Manual
Specifications
Display: 3 1/2 digit liquid crystal display (LCD) with maximum reading of 1999
Overrange: (OL) or (-OL) is displayed
Low battery indication: The ” ” is displayed when the battery voltage drops below the operating level
Measurement rate: 2.5 times per second, nominal
Operating Environment: 0°C to 40°C at < 70% relative humidity.
Storage Temperature: -20°C to 60°C, 0 to 80% R.H. with battery removed from meter
Auto power off: 15 seconds approx
Standby consume current: <10μA
Battery: 4 pcs 1.5V (AAA size) UM-4 R03.
Battery Life: 4 hours (continuity) typical with alkaline battery (@20ΜΩ range test 10ΜΩ resistor).
SKU SMG5 Brand Fieldpiece Shipping Weight 0.9000kg Shipping Width 0.120m Shipping Height 0.120m Shipping Length 0.300m Shipping Cubic 0.004320000m3 Unit Of Measure ea Assembled Length 0.300m Assembled Height 0.120m Assembled Width 0.120m
